Assignment III Translator for a multithreaded language.



In this assignment you have to build a compiler for the multithreaded language defined below. We will recommend that you use lex/flex as the lexical analyzer and yacc/bison as the parser for this assignment.



The following is the description of the constructs supported in the multi-threaded language. At the top of the hierarchy is a system. A system is defined as a set of communicating processes. These processes communicate through messages which are declared globally across the system. We now define what a process is. A process has a set of local declaration in a code block and has a start node and an end node which are markers of the process. It supports the following constructs:

i)                     Block A block of code

ii)                    Decision Construct

iii)                   Message Send Construct

iv)                  Message Receive Construct

v)                   GOTO construct



The block of code is a piece of C-code which may or may not use the variables declared locally in the process. Every block is marked by an identifier which uniquely identifies the code block in the process space. A decision construct decides on the control flow of the language. The GOTO construct is an unconditional jump construct. All jumps are within the process space. The messages send/receive constructs are used to exchange messages globally across the various processes.



We now define the syntax of the specification: (All keywords are in CAPS)



SYSTEM sysid;

//sysid System Identifier



SIGNAL sigid1, sigid2, sigid3;

//sigid Signal Identifier



PROCESS pid1, pid2, pid3;

//pid Process Identifier



PROCESSDEF pid1

//Process Definition

START

PROCESSBODY

END

PROCESSBODY as defined earlier is a collection of the four kinds of constructs. We define these constructs in more detail now:



BLOCK construct:

BLOCK blockid //Block identifier

START

Standard C code - Anything

END



If the blockidentifier blockid is not defined in the process scope, it is an error condition. C code is standard C-code.

DECISION construct:

DECISION decisionid //Decision identifier

IF condition

THEN

GOTO blockid_true

Optional - ELSE

Optional - GOTO blockid_false



If the blockidentifiers blockid_false and blockid_true are not defined in the process scope, it is an error condition.



UNCONDITIONAL JUMP:

This is a jump with just one GOTO statement. The syntax is:

UNCONDDEC undecid //Identifier to this block

GOTO blockidentifier



If the blockidentifier is not defined in the process scope, it is an error condition.



MESSAGE Send and Receive:

SEND (messageid)

RECEIVE (messageid)



Messageid should be in the list of signals defined in the global scope otherwise it is an error.



All the identifiers follow standard C identifier based rules.





Translation into Threaded C-code



-          Each of the process is translated to threads in Unix/Linux.

-          Each send/receive message is to be done through named pipes which are blocking.



There are two stages in the assignment:

Stage I: There is just one process and you have to generate sequential C-code from the specification.

Stage II: There are multiple processes and there are message send/receives.







The SYSTEM/PROCESS/SIGNAL lines are redundant in this sequential code generation process. They will be used in the later stage of the assignment.



Message Passing will be described in more detail in the second part of the assignment.

A more detailed figurative example:



//Finding the largest and the second largest in a set of numbers





Fig 1: Input in Graphical Format



Actual C-Code which depicts the second maximum and maximum finding algorithm.

#include<stdio.h>

main(){



int i=0,j=0;

int a[5];

int max, secondmax;



a[0] =3456;

a[1]=32;

a[2] =4542;

a[3]=1;

a[4]=56;



for(i=0;i<5;i++){



if(a[i]>max) {secondmax = max; max = a[i];}

else {

if(a[i] > secondmax) secondmax = max;

}

}

}



The Actual C- code.





The C-code with unstructured GOTO statements is acceptable but NOT desirable. There will be some penalty.



Input for Stage - I: SecondMax and Max



SYSTEM mysystem;

SIGNAL s1;

PROCESS pid1;



PROCESSDEF pid1

START



BLOCK myblock1

START

int i=0,j=0;

int a[5];

int max, secondmax;

a[0] =3456;a[1]=32;a[2] =4542;a[3]=1;a[4]=56;

END



DECISION mydec1

IF i < 0

THEN

GOTO mydec2

ELSE

GOTO myblock8





DECISION mydec2

IF a[i] > max

THEN

GOTO myblock4

ELSE

GOTO mydec3







BLOCK myblock4

START

secondmax = max; max = a[i];

END



DECISION mydec3

IF a[i] > secondmax

THEN

GOTO myblock7

ELSE

GOTO myblock5



BLOCK myblock5

START

i=i++;

GOTO mydec1;

END



BLOCK myblock7

START

secondmax a[i];

GOTO myblock5;

END



BLOCK myblock8

START

printf("max = %d, secmax = %d\n",max,secondmax);

END





END









Hint: Solution Methodology





Each and every construct can in the number as has been done in the Figure earlier. We first construct a graph out of it using a DFS of the parse tree. The IDs marked in RED are assigned to the various blocks in the specification according to topological sorted order.



The tree constructed looks like this:









The code generated for the above example will be as follows:



C-Code for node 1;

If(condition of Node 2){

If(condition of Node 3){

C- Code for Node 4;

} else if(condition for Node 6){

C- Code for Node 7;

}

C-code for node 5;

//Generate a goto here

goto node2;

} else {



C- code for Node 8.



}
